3 Best Questions About Decompression Hydraulic Circuit

3 Best Questions About Decompression Hydraulic Circuit

Szacowany czas czytania: 8 minuty

Hydraulic Circuit using a pressure-reducing valve Figure 15 allows a cylinder or stroke in the circuit to operate at a low relief valve set pressure. A pressure-reducing valve with a check valve is designed so that when the piston returns, the oil flow passes through the check valve without passing through the pressure-reducing element. Hydraulic Circuit

Hydraulic Circuit
15. Obwód redukcyjny ciśnienia za pomocą zaworu redukcyjnego

1. Projekt obwodu redukcyjnego ciśnienia, aby zwrócić uwagę na problem

  • Leakage problem of pilot operated pressure reducing Hydraulic Circuit

Be aware of the pilot-operated pressure reducing valve leakage than other control valves. The leakage of this valve can be as much as 1L / min or more. As long as the valve is in working condition, the leakage is always present. In the choice of hydraulic pump capacity, take this into full consideration. It should note that the minimum adjustment pressure of the pressure-reducing valve should ensure that the difference between the primary and the secondary is 0.31MPa. Hydraulic Circuit

  • Wtórny problem niestabilności ciśnienia

The damping hole of the main spool of the pressure reducing valve is blocked so that the oil exported from the pressure reducing valve cannot flow smoothly into the capacitive cavity between the main valve and the pilot valve. And the pilot valve also reduces the control role of the secondary pressure exported from the pressure reducing valve, resulting in unstable secondary pressure. Hydraulic Circuit

2. Decompression Hydraulic Circuit component setting problem

As shown in Figure 16, the pressure in the branch circuit cylinder 2 after the pressure-reducing valve 3 is lower than the fluid pressure in the master cylinder 1 branch circuit, which is called a pressure reducing circuit. The problems of this circuit are as follows. Hydraulic Circuit

  • When cylinder 2 is stopped for a long time, the secondary pressure after pressure reducing valve 3 gradually increases. This is because when cylinder 2 is stopped for a long time, a small amount of oil is discharged through the pilot valve through the spool gap to keep the valve in working condition. Due to the leakage in the valve, the flow through the pilot valve increases, and the secondary pressure (outlet pressure) of the pressure-reducing valve increases. To prevent this failure, you can add the oil circuit shown in the dashed line in the pressure reducing circuit, and install a safety valve at b to ensure that the pressure reducing valve outlet pressure does not exceed its adjustment Hydraulic Circuit.
1-siłownik główny; Cylinder 2-gałęziowy; 3-zawór redukcyjny; Zawór dławiący 4-A
16. 1-siłownik główny; Cylinder 2-gałęziowy; 3-zawór redukcyjny; Zawór dławiący 4-A
  • The speed adjustment of the hydraulic cylinder in the pressure reducing circuit is not working or the speed is not stable. As shown in Figure 16, this problem occurs when the leakage of pressure-reducing valve 3 (the fluid flowing back to the tank from the pressure-reducing valve drain port) is large. The solution is to change the throttle valve from the position in the figure to connected in series at an after the pressure reducing valve, to avoid the effect of pressure reducing valve leakage on the speed of cylinder 2. Hydraulic Circuit

3. Niestabilne ciśnienie robocze obwodu redukcyjnego ciśnienia

In the system shown in Figure 17, the hydraulic pump is quantitative, and the hydraulic cylinders 7 and 8 in the main oil circuit are controlled by two-position four-way electro-hydraulic reversing valves 5 and 6 respectively to control the direction of motion, and the control fluid of the electro-hydraulic reversing valves comes from main oil Hydraulic Circuit.

Obwód redukcyjny jest połączony równolegle z głównym obwodem olejowym i jest rozprężany przez reduktor ciśnienia 3. Dwupołożeniowy czterodrogowy zawór elektromagnetyczny steruje kierunkiem ruchu siłownika hydraulicznego 9.

The electro-hydraulic reversing valve controls the return line of the oil circuit and the external drain of the pressure reducing valve. The oil circuit merges and return to the tank, and the operating pressure of the system is regulated by the relief valve2. Hydraulic Circuit

The main oil circuit in the system works normally, but in the pressure reducing circuit, the pressure downstream of the pressure reducing valve fluctuates greatly, so that the working pressure of hydraulic cylinder 9 cannot be stabilized at the regulated pressure value of 1MPa. Hydraulic Circuit

Przykład układu o niestabilnym ciśnieniu na wylocie reduktora ciśnienia1 pompa stała; 2 - zawór nadmiarowy; 3 - zawór redukcyjny ciśnienia; 4 dwupołożeniowy czterodrogowy zawór przełączający sterowany elektromagnetycznie; 5,6 - dwupołożeniowy czterodrogowy elektrohydrauliczny zawór przełączający; 7 do 9 - siłownik hydrauliczny; 10 - manometr
17. Przykład instalacji z niestabilnym ciśnieniem na wylocie reduktora ciśnienia
1 stała pompa; 2 – zawór nadmiarowy; 3 – zawór redukcyjny; 4 dwupołożeniowy czterodrogowy zawór przełączający sterowany elektromagnetycznie; 5,6 – dwupołożeniowy czterodrogowy elektrohydrauliczny zawór rewersyjny;
7 do 9 – siłownik hydrauliczny; 10 – manometr

In the pressure reducing circuit, the downstream pressure of the pressure reducing valve, the working pressure of the pressure reducing circuit, occurs in large fluctuations is a frequent failure phenomenon, the main reasons for which are the following. Hydraulic Circuit

  • The prerequisite for a pressure reducing valve to be able to stabilise the pressure downstream of the valve at the regulated value is that the upstream pressure of the pressure reducing valve should be higher than the downstream pressure, otherwise the pressure downstream of the pressure reducing valve cannot be stabilised. Main hydraulic circuit working pressure change significantly. Hydraulic Circuit

It will have a larger impact if the minimum pressure value changes lower than the downstream pressure of the pressure-reducing valve, this is because when the upstream pressure of the pressure reducing valve is increase, the downstream pressure may have to be increase instantaneously, but through the regulating action of the pressure reducing valve it will quickly return to the regulating valve. Conversely, when the upstream pressure of the pressure-reducing valve reduces, the downstream pressure of the pressure-reducing valve should reduce instantaneously, and the pressure-reducing valve will quickly adjust so that the downstream pressure rises to the regulated value. Hydraulic Circuit

Jeżeli ciśnienie przed zaworem zmienia się, a jego ciśnienie minimalne jest niższe od ustalonej wartości ciśnienia za zaworem, ciśnienie za zaworem musi być odpowiednio zmniejszone i nie może ustabilizować się na regulowanej wartości ciśnienia.

Dlatego też w przypadku zmian obciążenia siłownika głównego obwodu olejowego w warunkach pracy, gdy minimalne ciśnienie robocze jest niższe niż ciśnienie za zaworem, projekt obwodu powinien podjąć niezbędne środki, takie jak dodanie zaworu zwrotnego, dodanie akumulatora między zawór zwrotny i zawór redukcyjny ciśnienia itp., aby zapobiec zmianom ciśnienia przed zmianą poniżej ciśnienia na dopływie.

  • Obciążenie siłownika jest niestabilne. W obwodzie redukcyjnym ciśnienie za zaworem jest stabilne tylko dzięki efektowi regulacyjnemu zaworu redukcyjnego. Przy wystarczającym obciążeniu siłownika, ciśnienie wylotowe nadal musi być zgodne z obiektywnym prawem, to znaczy ciśnienie powinno być określone przez obciążenie. Żadne ciśnienie nie może powstać bez obciążenia, a ciśnienie jest niższe przy niskim obciążeniu. Jeżeli w obwodzie reduktora ciśnienie za reduktorem ustawione jest w stanie obciążenia w określonym momencie, ale w trakcie pracy reduktora, przy zmniejszeniu obciążenia, ciśnienie za reduktorem powinno zmniejszyć do zera. Przy ponownym wzroście obciążenia wzrasta ciśnienie za reduktorem ciśnienia, a gdy ciśnienie wzrasta wraz z obciążeniem do ciśnienia regulacyjnego reduktora, ciśnienie nie wzrasta wraz z obciążeniem, lecz pozostaje na ciśnieniu regulacyjnym wartość zaworu redukcyjnego ciśnienia.

Dlatego w warunkach zmiennego obciążenia zmienia się wartość ciśnienia za reduktorem ciśnienia, a zmiana ta może być tylko niższa niż wartość regulacyjna zaworu redukcyjnego, ale nie wyższa niż wartość regulacyjna.

  • W zewnętrznym przewodzie odpływowym występuje przeciwciśnienie. Linia sterująca zaworu redukcyjnego jest zewnętrznym przewodem spustowym. płyn sterujący otwiera zawór stożkowy, a następnie oddzielnie wraca do zbiornika. Jeżeli w zewnętrznym przewodzie spustowym zmienia się ciśnienie wsteczne, wpływa to bezpośrednio na ciśnienie oleju ciśnieniowego popychającego zawór stożkowy, powodując zmianę ciśnienia, a tym samym zmianę ciśnienia roboczego za reduktorem ciśnienia.

Zjawisko usterki w układzie pokazane na rysunku 17 jest analizowane przez inspekcję i jest spowodowane zmianą ciśnienia wstecznego w zewnętrznym obwodzie odprowadzania oleju zaworu redukcyjnego.

It is easy to see that the electro-hydraulic reversing valves 5 and 6 in the system is changing in the process of reversing the flow and pressure of the return oil in the control oil circuit. The oil in the external drainage circuit of the pressure-reducing valve is also fluctuating, and the two streams of oil merge to produce unstable backpressure.

After debugging, when the electro-hydraulic reversing valves 5 and 6 act at the same time, the pressure gauge 10 reads 1.5 MPa. This is because the electro-hydraulic reversing valve is under the action of a high-pressure control fluid, the instantaneous flow is larger, and in the case of a longer drain pipe, higher backpressure is generated, the backpressure increases. So that the main valve opening of the pressure reducing valve increases, and the local pressure at the valve opening decreases, so the working pressure of the pressure reducing valve increases.

Aby wyeliminować tę usterkę, przewód spustowy reduktora ciśnienia i elektrohydrauliczny zawór przełączający 5 i 6 należy podłączyć z powrotem do zbiornika oleju oddzielnie, tak aby przewód spustowy reduktora ciśnienia mógł płynnie spływać z powrotem do zbiornika oleju bez zakłóceń i wahania, a ciśnienie wylotowe będzie stabilne przy regulowanej wartości ciśnienia.

Z powyższej analizy wynika, że podczas projektowania i instalacji systemu, rozumiejąc wydajność pracy poszczególnych elementów, należy dokładnie rozważyć, czy elementy będą ze sobą kolidować.
